RTS’ Ford 9†fabricated rear axle housings are CAD designed to be as light as possible and laser cut for a great surface finish. Their triangulated design provides the structural integrity required for high performance racing applications or even for the street/strip. Constructed from mild steel, the outer shell is 3 mm thick and the faceplate is 6 mm thick. Configured for 9†diff gears, these housings come in a full-bodied car style, with cut to length 3†OD (0.18†wall) axle tubes which suit forged housing ends. Overall width of 60†and the faceplate accepts 3/8†studs and has a drain plug included.
_x000D_
_x000D_
Features:
_x000D_
_x000D_
_x000D_
Triangulated ridge design
_x000D_
1/4†fabricated steel center section
_x000D_
3†axle tubes (0.250†wall thickness)
_x000D_
3/8†thick mounting flanges
_x000D_
Clearance provided for cases with HD main caps
_x000D_
Housings will accept 9.0” and 9-1/2″ gear sets
_x000D_
Comes with center studs, billet fill plug, drain, and vent
