RTS OEM replacement axles are produced using state of the art equipment and manufacturing techniques. These 4140 Induction hardened steel axles shafts have hardened bearing seats and machined to fit directly into your factory fitted Ford 9 inch diff. They feature extra spline length on the end so they can be cut to fit your exact length in a modified situation. When quality is your aim, RTS axle shafts should be your choice. RTS Axle Decal included.

_x000D_
_x000D_

_x000D_
• Direct Fit for XT GT 8 inch , XW XY Length 9 inch diff

_x000D_

• Can be shortened to fit 65, 66 Ford Mustang with 8 inch and 9 inch diff

_x000D_

• 5 x 4.50″ Stud pattern

_x000D_

• Suits small bearing

_x000D_

• Brake drum hub 2.427 / 61.65mm

_x000D_

• .605″hole diameter for factory style press in wheel studs

_x000D_

• 100mm spline length allows for shortening

_x000D_

• Note, prior to fitting assembled axle you need to lubricate axle seal surface area to stop seal burn

_x000D_

• This is a street performance axle which exceeds oem strength/quality and not a high-powered race axle.

_x000D_

• Available in XR to XY length & XA onward length

_x000D_

• Dedicated Left and Right hand side length
