RTS 10″ performance converter mounting ring kit provides torque converter builders the components for producing low-cost, high performance converters for the GM TH350, TH400. Powerglide & Trimatic with Turbo Spline, Using this kit allows the use of the OE GM 245mm front cover.

_x000D_
_x000D_

Note

_x000D_
_x000D_

When using in a Powerglide application the impeller hub must mount .070″ taller. Either leave a .070″ boss on the impeller to extend the height when using the impeller hub included in the kits or use a GM-90-300G impeller hub and cut it down to 3.695″ length.

_x000D_
_x000D_

Contents

_x000D_
_x000D_

_x000D_
• Impeller Hub Butt-mount

_x000D_

• Turbine Hub 30-Tooth

_x000D_

• Conversion Pilot

_x000D_

• Front Cover Bushing

_x000D_

• Mounting Ring with 10¾” and 11½” bolt patterns

_x000D_

• Thrust Washer

_x000D_

• Countersunk Bolts (3)

_x000D_

_x000D_
_x000D_

Specs

_x000D_
_x000D_

_x000D_
• Unit Size: 10″

_x000D_

• Core: GM 245mm

_x000D_

• Dampered: No

_x000D_

• Lockup: No

_x000D_

• Transmission Unit: 350, 400, Powerglide

_x000D_

• Turbine Hub Input Spline Count: 30

_x000D_

_x000D_
