NZD $969.57
Chevrolet V8 11″ Billet Flywheel & Clutch Assembly, Release & Pilot Bearings and ARP Bolts
_x000D_
_x000D_
Save $$ by purchasing a RTS Clutch package which includes all the items associated with completing the job sucessfully
_x000D_
_x000D_
FLYWHEEL
_x000D_
_x000D_
RTS Explosion Proof billet steel flywheels are designed from the ground up to deliver high performance results. Starting with CAD engineering and tested to limits far above the SFI-ratings, these flywheels are then constructed from 4140 high-quality materials to ensure reliable results. These flywheels are sure to deliver what they promise:
_x000D_
_x000D_
Features include:
_x000D_
_x000D_
* CAD engineered
_x000D_
* 4140 Steel and Heat-treated ring gears
_x000D_
* Available in Standard finish or with a black oxide anti-corrosive finish
_x000D_
* CNC-machined finish
_x000D_
* Available in multiple configurations
_x000D_
_x000D_
Note: The black coating is a black chemical conversion coating (not physically coated) and will not affect clutch discs.
_x000D_
_x000D_
Clutch Kit
_x000D_
_x000D_
Extreme Clutch Stage 1A Sprung Organic Clutch Kits are recommended for Street use in vehicles with minor engine modifications.
_x000D_
_x000D_
Sprung organic clutch kits offer exceptional driveability for vehicles used daily but also have performance modifications. The sprung organic disc offers improved dampening which reduces the shock loading on the transmission.
_x000D_
_x000D_
| Specifications | |
|---|---|
| Flywheel Step (mm) | Flat |
| Clutch Disc Diameter (mm) | 280 |
| Clutch Disc Spline Count | 10 |
| Clutch Disc Spline Diameter (mm) | 28.6 |
| Disc Type | Sprung |
| Friction Material | Organic |
| Stage | 1 |
| Recommended Use | Street |
| Clamping Force % Increase | 15% |
| Torque (Nm) Inc FOS | 580 |
| Torque (ftlbs) Inc FOS | 430 |
| Spigot Bush/Bearing Included | Yes |
| Aligning Tool Included | Yes |
| Spline Grease Included | Yes |
| Transport Weight (kg) | 14.3 |
