RTS Billet Converter Kit

_x000D_
_x000D_

RTS 9.5″ Billet converter kit allows builders to assemble a high performance converter with minimal effort.

_x000D_
_x000D_

_x000D_
• Fully machined cover with bushing installed

_x000D_

• Unit-specific design for hassle-free installation

_x000D_

• Oil flow grooves and holes increase fluid flow to keep converters running cooler

_x000D_

• Turbine hub features a larger flanged diameter to increase the strength rigidity of the turbine

_x000D_

• Clear, detailed instructions

_x000D_

_x000D_
_x000D_

Contents

_x000D_
_x000D_

_x000D_
• Inner Stator Race

_x000D_

• Thrust Washer

_x000D_

• Flanged Impeller Hub

_x000D_

• Stud Covers (4)

_x000D_

• Pilot

_x000D_

• Billet Front Cover

_x000D_

• Front Cover Bushing (Installed)

_x000D_

• Set Screws (4)

_x000D_

• Turbine Hub 26-Tooth

_x000D_

_x000D_
_x000D_

Specs

_x000D_
_x000D_

_x000D_
• Unit Size: 9.5 “

_x000D_

• Core: GM 245mm

_x000D_

• Dampered: No

_x000D_

• Lockup: No

_x000D_

• Transmission Unit: C4

_x000D_

• Stack Height: 5.938″

_x000D_

• Bolt Circle Dia.: 11.50″

_x000D_

• Turbine Hub Input Spline Count: 26
