Proflow’s cast aluminum intake elbow is designed for a direct fit onto your 4150 intake manifold, accommodating both GM LS throttle bodies and Proflow’s universal 90mm cable throttle body. Its slotted mounting holes allow for versatile installation, enabling forward, backward, or sideways orientations.

_x000D_
_x000D_

Utilizing advanced CFD technology in its design, this elbow features an internal vane that optimizes fluid flow, ensuring even distribution across the manifold. This innovation helps avoid concentrated flow spots, resulting in a more consistent air-fuel mixture and improved volumetric efficiency. A 95mm bore size has been chosen over a larger 105mm to maintain optimal air velocity which enhances throttle response.

_x000D_
_x000D_

The elbow is port-matched to a standard 4150 gasket and has a 10-degree downward angle to ensure bonnet clearance. It is equipped with two 1/8″ NPT ports and one 1/4″ NPT port for vacuum accessory plumbing. Additionally, it comes with a throttle cable bracket and integrated bosses for secure cable mounting.

_x000D_
_x000D_

Features and Specs:

_x000D_
_x000D_

_x000D_
• Overall height of 127mm

_x000D_

• Large 95mm bore size with o-ring seal

_x000D_

• Suits a standard GM LS 92mm or 102mm throttle body (102mm needs slight clearancing)

_x000D_

• Suits Proflow 90mm unviersal cable throttle body (PFETBU90)

_x000D_

• Port matched to a 4150 flange

_x000D_

• 3x vacuum ports – 2x 1/8 NPT and 1x 1/4 NPT

_x000D_

• Includes a gasket, vacuum port plugs and throttle cable bracket

_x000D_

• Throttle cable bracket boss is positioned on both sides for your convenience

_x000D_

• Available in raw cast or black powdercoated finishes

_x000D_

_x000D_
_x000D_

Note: can be used with a 102mm LS throttle body with minor porting to allow clearance for the throttle blade.
