Proflow Cylinder Heads, AirMax 180, SB Chev, Aluminium, Assembled, 72cc Chamber, Angle Plug, 180cc Intake Runner, Pair

NZD $1,783.95

Out of stock

Proflow does not sacrifice quality for a low price–you get both with our aluminium cylinder heads. The lightweight heads are cast from A-356 aluminium alloy with a large choice of engine, for SB & BB Chevrolet, LS Chev Holden Ford SB 289-351W, 302, 351 Cleveland 2V & 3V & BB FE, and Chrysler SB & BB. They have phosphorous bronze valve guides, and ductile iron valve seats for use with unleaded gas. They’re also end-milled and drilled for accessories. The fully assembled heads have stainless steel valves, high performance valve springs, 7 degree valve locks, rocker arm studs, and guideplates. Perfect for your Mild or High performance Hot Rod.

_x000D_
_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

_x000D_

SPECIFICATIONS

_x000D_

Combustion Chamber   72 cc
Intake Port Volume   180 cc
Intake Port Dimensions   2.00” (H) x 1.20” (W)
Exhaust Port Volume   70 cc
Exhaust Port Dimensions   1.450” (H) x 1.550” (W)
Spark Plug Location   Angled
Intake Valve Diameter   2.020”
Exhaust Valve Diameter   1.60”
Valve Stem Diameter   11/32”
Valve Spring Pocket ID   1.49”
Valve Guide OD   0.530” (0.570” at base)
Maximum Valve Lift   0.530”
Rocker Stud Thread Size   7/16”-24
Valve Angle   23°
 Deck Thickness   0.750”
Installed Spring Height   1.790” @ 130lbs
