Compact for installation under floor or on firewall of almost any vehicle. Booster measures only 7″ in diameter. Cast iron master cylinder has a 1″ bore and is suited for disc-disc or disc-drum combinations.

_x000D_
_x000D_

Master cylinder features two 3/8″-24 inverted flare ports on each side (plugs are included for ports not in use).

_x000D_
_x000D_

_x000D_
• Compact design to fit into small spaces under the hood

_x000D_

• Universal in design, makes for a simple install

_x000D_

• Heavy-duty zinc-plated steel construction to provide years of service

_x000D_

• Uses standard DOT 3 or DOT 4 brake fluids

_x000D_

_x000D_
_x000D_

Specs

_x000D_
_x000D_

_x000D_
• Pushrod-to-mounting flange is 5-1/2″

_x000D_

• Four bolts on 3-3/8″ centers

_x000D_

• Booster is 3.75″ thick

_x000D_

• Master cylinder combo is 11.875″ from end of the master cylinder to the firewall

_x000D_

• (4) qty 3/8″-24 outlet ports (2 plugs included)

_x000D_

• 8″ from mount to outer edge
